INVADER
ENLIGHTEN YOUR COMFORT ZONE

INVADER

One look – boundless possibilities: With the INVADER spotlight – PROLICHT once again demonstrates the great flexibility of its range. INVADER is characterised by the ease with which it can be configured and tailored to any individual situation – its technical sophistication and its visual identity. Whether you’re looking for a WALLWASH or a PENDANT for pleasant restaurant lighting – something to set a dramatic scene in a retail-store or a harmonious lighting solution for a comfortable home – INVADER is a bespoke solution for every demand.

NEW: INVADER COMPACT

SET ACCENTS IN A COMPACT FORMAT

INVADER plays with color - the parts of the luminaire can be individualized in our 25 PROLICHT colors to set specific accents and contrasts in the ceiling. With a universal 68mm cut-out the different variants can be exchanged in order to deliver illumination exactly where it is needed.

MINIMAL SIZE - HIGH OUTPUT

Despite its handy format, INVADER COMPACT delivers the high output needed to create exciting lighting sceneries. In its two new versions COMPACT and COMPACT ADJUSTABLE our INVADER demonstrates the great flexibility of its range. The ADJUSTABLE version is perfectly suited to direct light on specific highlights without the need for tools. For concrete installations, a special version was created to complete it universal application.









TECHNICAL DESCRIPTION

Limitless applications and award-winning design raise INVADER to the upper echelons of custom lighting. Its outstanding visual comfort is achieved by the KORONA CONE – customisable in 25 colors to create a unique appeal.

REFLECTOR | Integrated reflectors ( 18°/25°/40°) with an excellent efficiency and an uniform light distribution without spectral colour appearances.

HEAT SINK | A optimised heatsink allows a lumen package up to 2950 lm with only a diameter of 150 mm maximum. The low recessed depth is a big advantage in applications with limited space.

KORONA CONE | The cone of INVADER is available in different heights. It gets simply screwed into the trimless housing. The cone is available in all 25+5 PROLICHT colours.

EASY MOUNTING | Ceiling thickness can be set aside – thanks to the easy mounting system for INVADER randlos. It ensures a perfect seamless integration in the ceiling.

EASY MOUNTING

Easy installation and tool-free access to the driver for maintenance purposes, even in a trimless mount, were the aims during the design process. In case of a recessed INVADER 85, a mounting frame with a small trim enables easy removal of the entire fitting. A similar click system is available for trimless situations, without damaging the plastered ceiling.

ONE FAMILY - ENDLESS POSSIBILITIES

Whether FIXED, ADJUSTABLE, WALLWASH, WALL-MOUNTED or SUSPENDED, any INVADER variant can be used in demanding lighting designs, maintaining the same look. Different sizes (Ø40/75/85 and 150 mm) – trimless or recessed – and a range of fitting cone depths provide the best possible configuration solutions for residential applications, shops, hotels or restaurants.



PROLICHT DNA

INVADER is characterised by the ease with which it can be configured and tailored to any individual situation. By selecting the colour of the outside and the cone, the LED colour temperature, the beam angle and even the colour of the suspended power feed cable – a unique product is born with the designer’s personal touch. PROLICHT's unique DNA enables it to “make the difference”, providing added value for designers.



KORONA CONE

The high precision – deep reflector directs the light effectively past the cone without changing the light colour. However – the coloured cone does alter the effect of the light. Simply switch on the lights for a real wow effect: the coloured cone reflects the light in such a way that it appears to be lit from within. The cone can be personalised in a range of colours. KORONA is also a perfect solution to match with the interior or for branding.

HANGOVER

The INVADER HANGOVER pendant luminaire is based on the latest reflector technology and offers multiple configuration options. Whether size, color, or LEDs, there are no limits to creating a customized design. It can be implemented in various tracks or as a stand-alone variant with canopy and is available with a GRAVITY LIFT option to shorten or lengthen its cable at will.

Technical data

Product INVADER INVADER DEEP INVADER ADJUSTABLE INVADER COMPACT INVADER COMPACT ADJUSTABLE
INVADER INVADER DEEP INVADER ADJUSTABLE INVADER COMPACT INVADER COMPACT ADJUSTABLE
Mounting Option Trimless Trimless Trimless Trimless Trimless
Dimension
H 49: ⌀ 39
H 72: ⌀ 39
H 99: ⌀ 71
H 58: ⌀ 39
H 80: ⌀ 39
H 124: ⌀ 71
H 126: ⌀ 90
H 52: ⌀ 75
H 75: ⌀ 75
Lumen 160 - 1063 160 - 986 770 - 990 804 - 1012 772 - 821
Watt 2.3 - 14.7 2.31 - 14.74 13.4 - 14.7 11.2 - 12 11.2 - 12
LED / CCT 2700K, 3000K, 4000K, NATURALDIM 2700K, 3000K, 4000K, NATURALDIM Natural Dim, 2700K, 3000K, 4000K 2700K, 3000K, 3500K, 4000K, NATURALDIM 2700K, 3000K, 3500K, 4000K, NATURALDIM
Control
DALI Dim
depending

Some
Some

Some
Some

Some
Some

No
Yes

No
Yes
Protection Rate
IP20
IP44
IP40

Yes
No
No

Yes
No
No

Yes
No
No

No
Yes
No

No
No
Yes
Ceiling Thickness 10mm, 12.5mm, 15mm 10mm, 12.5mm, 15mm 10mm, 12.5mm, 15mm 10mm, 12.5mm, 15mm, 25mm 10mm, 12.5mm, 15mm, 25mm
Beamwidth Superspot, Spot, Medium, Flood, Wideflood Superspot, Spot, Medium, Flood, Wideflood Superspot, Medium, Flood, Wideflood Superspot, Medium, Wideflood Superspot, Medium, Wideflood
Adjustability
swiveling
tilting
rotation

No
No
No

No
No
No

No
Yes
Yes

No
No
No

Yes
No
Yes
Product INVADER INVADER DEEP INVADER ADJUSTABLE INVADER WALLWASH INVADER COMPACT INVADER COMPACT CONCRETE INVADER COMPACT ADJUSTABLE HANGOVER PLUG FLAT HANGOVER PLUG 30 SHINE FLAT HANGOVER CLICKTRACK INVADER COMPACT ADJUSTABLE CONCRETE
INVADER INVADER DEEP INVADER ADJUSTABLE INVADER WALLWASH INVADER COMPACT INVADER COMPACT CONCRETE INVADER COMPACT ADJUSTABLE HANGOVER PLUG FLAT HANGOVER PLUG 30 SHINE FLAT HANGOVER CLICKTRACK INVADER COMPACT ADJUSTABLE CONCRETE
Mounting Option Recessed Recessed Recessed Recessed Recessed Recessed Recessed Suspended Suspended Missing_Product.Families.TechnicalData.Mounting. Missing_Product.Families.TechnicalData.Mounting. Recessed
Dimension
H 49: ⌀ 45
H 71: ⌀ 45
H 105: ⌀ 85
H 87: ⌀ 85
H 130: ⌀ 148
H 62: ⌀ 45
H 84: ⌀ 45
H 124: ⌀ 85
H 74: ⌀ 62
H 105: ⌀ 109
H 112: ⌀ 85
H 52: ⌀ 75
H 53:
⌀ 75 , ⌀ 95
H 75: ⌀ 75
H 150:
⌀ 40 , ⌀ 75
H 300: ⌀ 40
H 450: ⌀ 40
H 150: ⌀ 28
H 300: ⌀ 28
H 450: ⌀ 28
H 150: ⌀ 75
H 300: ⌀ 75
H 75: ⌀ 95
Lumen 160 - 2405 160 - 986 660 - 990 850 - 1080 804 - 1012 804 - 1012 772 - 821 782 - 857 389 - 446 857 0 772 - 821
Watt 2.3 - 25.94 2.31 - 14.74 6.8 - 14.7 13.4 - 14.7 11.2 - 12 11.2 - 12 11.2 - 12 9.8 6.46 9.8 0 11.2 - 12
LED / CCT 2700K, 3000K, 4000K, Natural Dim 2700K, 3000K, 4000K, NATURALDIM 2700K, 3000K, 4000K, Natural Dim Natural Dim, 2700K, 3000K, 4000K 2700K, 3000K, 3500K, 4000K, NATURALDIM 2700K, 3000K, 3500K, 4000K, NATURALDIM 2700K, 3000K, 3500K, 4000K, NATURALDIM 2700K, 3000K, 4000K 2700K, 3000K, 4000K 2700K, 3000K, 4000K 2700K, 3000K, 3500K, 4000K, NATURALDIM
Control
DALI Dim
depending
Nicht dimmbar

Some
Some
No

Some
Some
No

Some
Some
No

Some
Some
No

No
Yes
No

No
Yes
No

No
Yes
No

No
Yes
No

No
Yes
No

Some
No
Some

No
No
No

No
Yes
No
Protection Rate
IP20
IP44
IP65
IP40

Some
Some
Some
No

Some
Some
No
No

Some
Some
No
No

Some
No
Some
No

No
Yes
No
No

No
Yes
No
No

No
No
No
Yes

Yes
No
No
No

Yes
No
No
No

Yes
No
No
No

No
No
No
No

No
No
No
Yes
Beamwidth Superspot, Spot, Medium, Flood, Wideflood Superspot, Spot, Medium, Flood, Wideflood Superspot, Medium, Flood, Wideflood Superspot, Medium, Flood, Wideflood Superspot, Medium, Wideflood Superspot, Medium, Wideflood Superspot, Medium, Wideflood Superspot, Medium, Flood, Wideflood Superspot, Medium, Flood, Wideflood Superspot, Medium, Flood, Wideflood - Superspot, Medium, Wideflood
Adjustability
swiveling
tilting
rotation

No
No
No

No
No
No

No
Yes
Some

No
No
No

No
No
No

No
No
No

Yes
No
Yes

No
No
No

No
No
No

No
No
No


Yes
No
Yes
Product INVADER ON INVADER WALL
INVADER ON INVADER WALL
Mounting Option Surface Surface
Dimension
H 150: ⌀ 75
H 300: ⌀ 75
H 150: ⌀ 75
H 300: ⌀ 75
Lumen 670 - 770 390 - 1210
Watt 9.8 - 14.7 6.7 - 14.7
LED / CCT 2700K, 3000K, 4000K, Natural Dim 2700K, 3000K, 4000K, Natural Dim, 2700K / 2700K, 3000K / 3000K, 4000K / 4000K
Control
DALI Dim
Nicht dimmbar

Some
Some

Some
Some
Protection Rate
IP20

Yes

Yes
Beamwidth Superspot, Medium, Flood, Wideflood Superspot, Medium, Flood, Wideflood
Product HANGOVER PLUG 30 HANGOVER PLUG 30 SHINE HANGOVER HANGOVER PLUG
HANGOVER PLUG 30 HANGOVER PLUG 30 SHINE HANGOVER HANGOVER PLUG
Mounting Option Suspended Suspended Suspended Suspended
Dimension
H 150: ⌀ 28
H 300: ⌀ 28
H 450: ⌀ 28
H 150: ⌀ 28
H 300: ⌀ 28
H 450: ⌀ 28
H 150:
⌀ 40 , ⌀ 75
H 300:
⌀ 40 , ⌀ 75
H 450:
⌀ 40 , ⌀ 75
H 150:
⌀ 40 , ⌀ 75
H 300: ⌀ 40
H 450: ⌀ 40
Lumen 330 - 380 389 - 446 782 - 1516 782 - 857
Watt 6.4 6.46 9.8 - 20.02 9.8
LED / CCT 2700K, 3000K, 4000K 2700K, 3000K, 4000K 2700K, 3000K, 4000K 2700K, 3000K, 4000K
Control
Casambi
DALI Dim
Nicht dimmbar

Some
Some
Some

Some
Some
Some

Some
Some
Some

Some
Some
Some
Protection Rate
IP20

Yes

Yes

Yes

Yes
Beamwidth Superspot, Medium Superspot, Medium, Flood, Wideflood Superspot, Medium, Flood, Wideflood Superspot, Medium, Flood, Wideflood
;
